Toggle Type Vertical Injection Moulding Machine

Kamal Engineering

VERTICAL INJECTION MOULDING MACHINE SERIES
1) VERTICAL INJECTION & HORIZONTAL CLAMPING
2) VERTICAL SCREW TYPE INJECTION MOULDING MACHINE
3) FULL MICROPROCESSOR PLC TYPE
4) POWER SAVING SERVO TYPE
5) FULL AUTOMATIC TOGGLE TYPE CLAMPING

We, at Kamal engineering established our operations in the year 2016, and are one of the leading and biggest manufacturers of a comprehensive range of toggle Injection Moulding Machines. Owing to our high quality and reliable products as well as a large product portfolio, we are dominating the market throughout Ahmedabad and India. All our machines are designed using state of the art raw materials and quality tested components in adherence to the predefined industry standards and norms. Being the leading toggle injection moulding machine manufacturer, we use modern manufacturing processes and advanced technologies to maintain the quality and flawlessness of our products.

Boasting of a state of the art production unit that is set up with multiple kinds of machines and tools and modern & advanced technology in the market, we are dedicated to manufacturing high end, high speed and high precision Toggle type Injection Moulding Machines. We are extremely concerned with fulfilling the precise needs of our clients and thus we offer customized machines in numerous specifications. Backed by an expert and experienced team of professionals, we produce innovative and long lasting toggle type injection moulding machine. Our experts are highly qualified and competent to understand the diversified requirements of our prestigious customers. This has helped us create value for our esteemed customers.

Being a leading manufacturer, we always aim for customer satisfaction and provide a high performance and defect free range of products. Due to this we have earned a huge client base from various industries such as electrical, automobile, telecommunication, and rubber industries. We diligently care for the utmost convenience of our customers and provide the most reliable and turnkey solutions.

Specification

UNIT

KE-60ST

KE-100ST

KE-150ST

KE-200ST

KE-300ST

KE-500ST

Screw Diameter

mm

30

35

40

45

45

55

Injection Pressure

kg/cm2

1700

1600

1500

1500

1500

1400

Theoretical Shot Volume

cm3

71

130

207

251

251

275

Max. Shot Weight

g

50

100

150

200

300

500

Injection Rate

cm3 / sec

57

83

90

114

114

167

Screw Stroke

mm

100

140

170

200

250

350

Screw Speed Max.

rpm

0-250

0-250

0-250

0-250

0-250

0-200

Nozzal Reaction Stroke

mm













Number Of Temprature



4

4

4

4

4

5

Matrial Hopper Capacity

I

10

10

15

20

20

20

Clamping Force

tons

7

10

13

18

18

25

Opening Force

tons

1.5

2.6

3.1

4

4

6.1

Distance Between Tie Bar

mm

200×200

260×260

310×310

340×340

360×360

400×400

Min. Mould Hight

mm

100

100

100

100

100

125

Opening Stroke

mm

210

300

325

460

470

550

Max. Open Daylight

mm

350

470

550

670

670

780

Ejector Force

tons

1.3

1.3

1.3

2

2

2

Ejector Stroke

mm

50

70

70

70

70

70

Slide Stroke

mm

120

150

150

150

200

250

Max. Hydraulic Pressure

kg/cm2

120

120

120

120

120

120

Pump Output

litter/min

20

26

26

40

40

60

Oil Capacity

liter

100

120

120

150

150

200

Pump Motor

kw

2.2

3.5

3.5

5.5

5.5

10

Barrel Heating Power

kw

3.2

4.1

4.1

4.1

6

6.5

Total Wattage

kw(HP)

5.4(7.24)

7.6(10.2)

7.6(10.2)

9.6(12.8)

10.5(14)

16.5(22.1)

Machine Weight Approx

tons

1.7

1.9

2.5

2.5

3.5

4

Machine Size Approx

m

1.8x1x2.48

2.1×1.1×2.8

2.2×1.2×3

2.2×1.3×3.1

2.4×1.2×3.4

2.7×1.5×3.4
